Martin wrote:Two types of chipsets used in serial to usb converters, progressive & FTDI which chipset does the converter you have bought use?? You need an FTDI chipset, most of the connection problems with plotters are caused by the other type. Once you have the right converter set it up as a virtual serial port & then treat setting up the plotter as you would if the laptop DID have a serial port., Thanks for the reply but we aren't using a converter just a direct USB link from the laptop to the cutter. The cutter was attached to a PC running XP. We want to attach it to a unit running Win 7, so assume it's just a Win 7 USB Driver for the Foison that we need. Hadn't thought of a USB / Serial converter so prhaps that's an alterative we could investigate bearing in mind your comments. You mentioned that the laptop had no serial port in your first post so I assumed that was how you had it connected to the PC, found this on another site cracked it!
I decided to think outside of box and installed it through Windows 7 manually. Start Control Panel Hardware & Sound Add A Device Then follow on screen instructions for adding device making sure that device is turned on and connected to PC I know what you mean about XP & Windows 7. I had to replace a perfectly good Canon Scanner which would not work under Windows 7.
& this seems to be a download for the driver, says it is compatible with windows 7 both 32 & 64 bit versions.
If you cannot get your cutter working, check that you've followed these steps carefully. 1) Turn your cutter off, and plug it into a free USB port on your computer. The new hardware wizard should appear, or if you've already done this, it should go 'Bing Bong' 2) On the cutter, Keep hitting 'Menu' until you see the setting for 'Baud.'
Vinyl Cutter Driver Download
The value should read 0. If it does not, use the arrow keys to make that so. Then, hit mode until you see normal screen FOISON. 3) Make a note of the Com port and set the flow control.
To do this: Go to Start, and then Run. In the box enter: devmgmt.msc or right click 'my computer'-properties-device manager-ports.Then, hit OK. 4) Hit the plus sign next to 'Ports COM And LPT' 5) You should see 'USB Serial Adapter', Right click on this and go to 'Properties' 6) From there, select 'Port Settings'.Adjust the Boud Rate as per cutter setting. Set the flow control to 'X-ON/X-OFF' 7) Hit 'Advanced', Make a note of the Com Port, and if possible change it to something 1-4 if they're not in use. Hit apply and OK to leave those menus. Close device manager. Adi shankaracharya movie.
9) Open Flexi, use the 'T' on the left hand side to type a couple of letters. 10) Go to File, then hit 'Cut/Plot' 11) This opens the Cut Plot screen. In the top left you should see CM-24 @ com x or CX-24 @ com x. The x needs to match up with the com port we noted earlier.
Redsail Vinyl Cutter Driver Download
If it does not: 12)Hit the properties button under theCM-24 @ com x drop down box. Select the right hand most tab. It has a picture of something that looks like a microphone.
Foison Vinyl Cutter Driver Download Windows 10
13) At the top, change the com port to match yours. Hit OK 14) At the bottom, make sure 'Flow Control' says 'X-ON/X-OFF'.
